Belimo B263 2-1/2 Inch 2-Way CCV Stainless Steel Trim 110 Cv High Performance Valve Actuator

Product Description

Introducing the Belimo B263, a 2-1/2 inch 2-way CCV valve with a stainless steel trim and a Cv value of 110. Specifically designed for optimal control of hot and cold water in HVAC systems, this valve promises long service life and reliable performance. The robust construction ensures a tight shut-off, minimizing leaks and maintenance requirements.

• Stainless steel trim helps withstand harsh conditions.
• Cv value of 110 for effective fluid control.
• Engineered for both heating and cooling applications.

Product Highlights

The Belimo B263 valve is typically used in air handling units for heating or cooling coils and fan coil unit heating or cooling coils. It's also effective for applications including Unit Ventilators, VAV box reheat coils and bypass loops. This valve is an essential component in hydronic systems with variable flow, proving its versatility across different setups.

Product Information

Technical Specifications

• Brand: Belimo
• MPN: B263
• Valve Size: 2.5 inches
• Valve Type: 2-way, CCV
• Trim: Stainless Steel
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Pressure: Non-independent
• Flow Range: Controllable
