Belimo B261+ARX24-SR-T N4 CCV Assembly 2 Way 2 1/2 in NPT 60 Cv

Product Description

The Belimo B261+ARX24-SR-T N4 is a characterized control valve designed for HVAC applications. This valve is suitable for use in air handling units and fan coil unit heating and cooling coils. Its robust construction includes a forged brass body and stainless steel components, ensuring durability and reliability.

• Designed for heating and cooling coils in HVAC systems.
• Features a ball valve design for self-cleaning and zero leakage.
• Rated for water temperatures up to two hundred fifty degrees Fahrenheit.

Product Highlights

This valve is ideal for hydronic systems with variable flow. The actuator type is non-spring return and operates on twenty-four VAC for use with two to ten VDC or four to twenty mA control signals.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B261+ARX24-SR-T N4

Technical Specifications

• Flow Characteristic: Equal Percentage
• Close-Off Pressure: 100 psi
• Power Consumption: 2.5 W Running, 0.4 W Holding
• Operating Conditions: -22 F To 122 F (-30 C To 50 C)
• Electrical Connection: Terminal Block
• Valve Size: 2.5 inches
• Service: Chilled, Hot Water, Up To 60% Glycol
• Angle of Rotation: 90 degrees
