Belimo B252 ARX24-SR-T N4 CCV Assembly 2 Way 2 in NPT 85 Cv

Product Description

The Belimo B252 ARX24-SR-T N4 is a characterized control valve designed for HVAC applications. This valve provides reliable flow control in various heating and cooling systems. It is constructed with a nickel-plated brass body and features a stainless steel ball and stem. The valve operates with a direct-coupled actuator and runs on 24 VAC or DC power. This non-fail-safe valve is suitable for modulating control signals of 2 to 10 VDC or 4 to 20 mA.

• Suitable for air handling units and fan coil units
• Works well with variable flow hydronic systems
• Simple installation and integration into existing systems

Product Highlights

This valve is ideal for applications such as unit ventilators, VAV box reheat coils, and bypass loops.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B252 ARX24-SR-T N4

Technical Specifications

• Valve Size: 2 inches
• Cv: 85
• Angle of Rotation: 90 degrees
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Control Type: DC 2 to 10 V
• Degree of Protection: IP66/67 NEMA 4X
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
