Belimo B249+AFRB24 CCV 2 2 Way 46 Cv w/ Spring Return 24V On/Off

Product Description

The Belimo B249+AFRB24 is a CCV valve actuator designed for various fluid control applications. It features a 2-inch 2-way valve with a flow coefficient of 46 and operates with a 24V spring return mechanism for reliable on/off control.

• Two-way valve with a 46 Cv rating
• Spring return functionality
• 24V on/off control

Product Highlights

Ideal for use with chilled or hot water systems containing up to 60% glycol. Provides reliable fluid control with a stainless steel trim and internal threaded end fittings.

Product Information

Standard Information

• Brand: Belimo
• MPN: B249+AFRB24

Technical Specifications

• Cv: 46
• Valve Size: 2 inches (50 mm)
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 2-way
• End Fitting: Internal thread
• Trim: Stainless steel
• Control Type: On/Off
• Voltage AC/DC: AC/DC 24V
• Actuator Type: Spring return
• Manual Override: 5 mm hex crank (3/16 Allen) supplied
• Power Consumption (Holding): 2.5 W
• Power Consumption (Running): 5 W
• Running Time (Motor): 75 s / 90°
• Running Time (Fail-safe): < 20 s
• Electrical Connection: Cable
• Angle of Rotation: 90°
• Controllable Flow Range: 75°
• Degree of Protection: IP54 NEMA 2 UL Enclosure Type 2
