Belimo B240 ARX24-SR-T N4 CCV Assembly 2 Way 1 1/2 in NPT 37 Cv

Product Description

The Belimo B240+ARX24-SR-T N4 is a characterized control valve designed for reliable operation in HVAC systems. This valve features a nickel plated brass body and a stainless steel ball and stem, ensuring durability and longevity. It is powered by a non-fail-safe direct coupled actuator operating at 24 VAC/DC. This product accommodates modulating control signals ranging from 2 to 10 VDC or 4 to 20 mA.

• Suitable for chilled or hot water up to sixty percent glycol
• 2-way valve design for effective flow control
• IP66/67 rated for protection against water and dust

Product Highlights

This valve is an essential component for precise HVAC control in both commercial and residential applications. It ensures efficient flow management and meets high standards for environmental protection.

Product Information

Standard Information

• Brand: Belimo
• Type: Control Valve

Technical Specifications

• Valve Size: 1.5 inches
• Cv: 37
• Fluid: Chilled or hot water up to 60% glycol
• Control Type: DC 2...10 V
• Manual Override: Under cover
• Running Time (Motor): 90 seconds per 90 degrees
• Power Consumption: 0.4 W (Holding), 2.5 W (Running)
• Electrical Connection: Terminals
• Degree of Protection: IP66/67 NEMA 4X
