Belimo B239+ARX24-SR-T N4 CCV Assembly 2 Way 1 1/2 in NPT 29 Cv

Product Description

The Belimo B239+ARX24-SR-T N4 is a characterized control valve designed for efficient control in HVAC systems. This valve features a nickel-plated brass body and stainless steel ball and stem. It operates with a direct coupled actuator and is non-fail-safe. Suitable for a modulating control signal of 2 to 10 VDC or 4 to 20 mA, it supports versatile application needs.

• Operates on 24 VAC/DC
• Designed for chilled or hot water with up to sixty percent glycol
• Features a 2-way pattern for effective flow control

Product Highlights

This control valve provides precise flow regulation and is suitable for HVAC installations requiring reliable performance.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B239+ARX24-SR-T N4

Technical Specifications

• Valve Size: 1.5 inches
• Cv: 29
• Control Type: DC 2 to 10 V
• Fluid: Chilled or hot water up to 60% glycol
• Pressure Independent: No
• Angle of Rotation: 90 degrees
• Degree of Protection: IP66/67, NEMA 4X
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
