Belimo B238+ARX24-SR-T N4 CCV Assembly 2 Way 1 1/2 in NPT 19 Cv

Product Description

The Belimo B238+ARX24-SR-T N4 is a characterized control valve designed for HVAC applications. This valve is used for controlling water flow in air handling units and fan coil units for both heating and cooling. It features a robust forged brass construction with a nickel-plated body which enhances durability and resistance to corrosion.

• Rated for water temperatures up to two hundred fifty degrees Fahrenheit.
• Ball valve design ensures self-cleaning and zero leakage.
• Operates with a torque rating of one hundred eighty inch-pound and powered by twenty-four volts AC.

Product Highlights

This valve is ideal for use in hydronic systems with variable or constant flow. It supports programmable control inputs and feedback signals, making it versatile for various HVAC needs.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B238+ARX24-SR-T N4

Technical Specifications

• Minimum Order Quantity: 1
• Operating Conditions: -22 F to 122 F (-30 C to 50 C)
• Close-Off Pressure: 200 psi
• Flow Characteristic: Equal Percentage
• Electrical Connection: Terminal Blocks
• Power Consumption: 2.5 W Running, 0.4 W Holding
• Service: Chilled, Hot Water, Up to 60% Glycol
• Degree of Protection: NEMA 4X, IP66/67
