BELIMO B238+AFRXUP-N4 CONTROL & CIRCUIT BOARDS
BELIMO B238+AFRXUP-N4 CONTROL & CIRCUIT BOARDS

Belimo B238+AFRXUPN4 CCV Assembly 2 Way 1 1/2 in NPT 19 Cv

BELIMO
Brand: BELIMO
SKU: B238+AFRXUP-N4
Ships in 4 - 5 Weeks
Same-day delivery
Greater Chicago, IL area
If ordered prior to 4pm CT (Mon-Fri)
$961.13
$961.13
Manuals:
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Belimo B238+AFRXUPN4 is a characterized control valve designed for effective flow regulation in HVAC systems. It has a two-way configuration and is compatible with both chilled and hot water applications. The valve features a nickel-plated brass body and a stainless steel ball and stem. Its direct coupled actuator with spring return operates within a voltage range of 24 to 240 VAC, providing reliable on/off control.

  • Compatible with 1.5 inch NPT piping
  • Pressure independent design.
  • IP66 NEMA4X rated for harsh environments.

Product Highlights

This valve ensures precise control of water flow in various HVAC settings, enhancing system efficiency.

Product Information

Standard Information

  • Brand: Belimo
  • MPN: B238+AFRXUPN4
Technical Specifications
Valve Size
1.5 [40]
Cv
19
Fluid
Chilled or hot water up to 60% glycol
Actuator Type
Spring return
Control Type
On/Off
Voltage AC/DC
AC24...240V / DC24...125V
Degree of Protection
IP66 NEMA4X
Running Time (Motor)
75 s / 90°
Power Consumption (Holding)
3.5 W
Power Consumption (Running)
7 W
