Belimo B232+ARX24-SR-T N4 CCV Assembly 2 Way 1 1/4 in NPT 37 Cv

Product Description

The Belimo B232+ARX24-SR-T N4 is a characterized control valve designed for HVAC systems. This valve features a nickel-plated brass body with a stainless steel ball and stem, along with a direct coupled actuator. It operates on 24 VAC/DC and modulates based on a control signal of 2 to 10 VDC or 4 to 20 mA.

• Non-fail safe actuator design
• Suitable for chilled or hot water applications with up to sixty percent glycol
• Compatible with internal threaded connections

Product Highlights

This valve is ideal for precise flow control in HVAC applications, ensuring reliability and efficiency in operation.

Product Information

Standard Information

• Brand: Belimo
• MPN: B232+ARX24-SR-T N4

Technical Specifications

• Valve Size: 1.25 inches
• Cv: 37
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Control Type: DC 2...10 V
• Actuator Type: Non fail-safe
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
• Degree of Protection: IP66/67 NEMA 4X
