Product Description
The Belimo B225+NRX24-MFT-TN4 is a characterized control valve designed for HVAC systems. It features a nickel plated brass body and stainless steel ball and stem. It operates with a direct coupled actuator that is non fail safe and runs on 24 VAC/DC.
- Flow capacity of thirty Cv.
- Suitable for chilled or hot water up to sixty percent glycol.
- Offers programmable control with MFT technology.
Product Highlights
This valve ensures efficient fluid control in varying conditions, making it suitable for a range of HVAC applications.
Product Information
Standard Information
-
Brand: Belimo
-
Part Number: B225+NRX24-MFT-TN4
Technical Specifications
-
Angle of Rotation: 90 degrees
-
Controllable Flow Range: 75 degrees
-
Cv: 30
-
End Fitting: Internal thread
-
Fluid: Chilled or hot water up to 60% glycol
-
Pattern: 2-way
-
Pressure Independent: No
-
Trim: Stainless steel
-
Valve Size: 1 inch (25 mm)
-
Actuator Type: Non fail-safe
-
Control Type: MFT/Programmable
-
Degree of Protection: IP66/67 NEMA 4X UL Enclosure Type 4X
-
Electrical Connection: Terminals
-
Manual Override: External push button
-
Power Consumption (Holding): 1.3 W
-
Power Consumption (Running): 3.5 W
-
Running Time (Motor): 150 seconds / 90 degrees
-
Voltage AC/DC: AC/DC 24 V
