Belimo B225+LF24 Characterized Control Valve 24V On/Off Replacement MPN

Product Description

The Belimo B225+LF24 is a characterized control valve designed for efficient temperature control in HVAC systems. This valve is primarily used in air handling units for heating or cooling coils, as well as in fan coil units. It is suitable for a range of applications including unit ventilators and VAV box re-heat coils. The valve operates effectively in hydronic systems with variable flow.

• Belimo part number B225+LF24
• 2-way valve with spring return
• 30 Cv flow coefficient

Product Highlights

This valve provides reliable performance in heating and cooling applications and supports both chilled and hot water.

Product Information

Standard Information

• Manufacturer: Belimo
• MPN: B225+LF24

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75 to 0
• Cv: 30
• End Fitting: Internal thread
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Pattern: 2-way
• Pressure Independent: No
• Trim Material: Stainless steel
• Valve Size: 1 inch (25 mm)
• Actuator Type: Spring return
• Degree of Protection: IP54 NEMA 2
• Electrical Connection: Cable
• Power Consumption (Holding): 2.5 W
• Power Consumption (Running): 5 W
• Running Time (Fail-safe): Less than 25 seconds
• Running Time (Motor): 75 seconds for 90 degrees
• Voltage: AC/DC 24 V
