Belimo B220B + LF24-SR- CCV - 0.75 - 2 Way - 14 Cv - w/ Spg Rtn - 24V - 2-10V - Belimo

Product Description

The Belimo B220B + LF24-SR is a control valve designed for use in HVAC applications. This valve efficiently regulates flow in heating and cooling systems. It is commonly applied in air handling units, fan coils, and other hydronic systems.

• Valve type: 2-way
• Supply voltage: 24V
• Flow capacity: 14 Cv

Product Highlights

This valve supports variable flow applications and is suitable for chilled or hot water systems with up to sixty percent glycol.

Product Information

Standard Information

• Manufacturer: Belimo
• Item Type: Control Valve

Technical Specifications

• Valve Size: 0.75 inches
• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75B0
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Chrome plated brass
• Actuator Type: Spring return
• Degree of Protection: IP54 NEMA2
• Electrical Connection: cable
• Power Consumption (Holding): 1 W
• Power Consumption (Running): 2.5 W
• Running Time (Fail-safe): less than 25 seconds
• Running Time (Motor): 150 seconds for 90 degrees
• Voltage AC/DC: 24 V
