Belimo ARB24-MFT Direct Coupled Actuator, 180 in-lb

Product Description

The Belimo ARB24-MFT is a direct coupled actuator designed for precise control in HVAC applications. This actuator provides a torque of 180 in-lb and operates on 24 VAC power supply. Suitable for modulating control, this product utilizes multi-function technology for effective performance.

• Torque: 180 in-lb
• Power Supply: 24 VAC
• Non-Spring Return

Product Highlights

This actuator is built with patented brushless DC motor technology for reliability and longevity, featuring a minimum torque guarantee over the entire specified operation range. It ensures performance stability across temperature fluctuations, supply voltage variations, and speed changes.

Product Information

Standard Information

• Manufacturer: Belimo
• MPN: ARB24-MFT

Technical Specifications

• Power Consumption: 3.5 W running, 1.3 W holding
• Operating Conditions: -22 F to 122 F (-30 C to 50 C)
• Electrical Connection: 3 ft, 18 GA plenum cable with 1/2 in conduit connector
• Angle of Rotation: 90 degrees
• Protection rating: IP54, NEMA 2
