Belimo AFB24-MFT-X1 Spring Return Actuator 24V

Product Description

Belimo AFB24-MFT-X1, a high-grade spring return valve actuator, operates on 24V to ensure optimal performance in HVAC systems. Essential for proportional modulation of dampers and control valves, this device guarantees reliable, fail-safe functionality.

• Integrated spring return mechanism provides dependable service.
• Fully modulating actuator allows for adjustable control settings.
• Robust construction designed for longevity in commercial HVAC setups.

Product Highlights

This actuator is widely reputed for its precise operation and adaptability in various environmental conditions. Equipped with a multi-function technology (MFT), it allows for custom configuration according to specific system requirements.

Technical Specifications

• Power Consumption: 7.5W (running), 3W (holding)
• Direction of Rotation: Reversible with built-in switch
• Dimensions: Weight: 5.07 lbs, Shipping Depth: 12 inches, Width: 6.13 inches, Height: 4.25 inches
• Modulation Range: 2 to 10 VDC
• Fail Safe Mode: Mechanical spring return ensures operation in event of power failure.
