Belimo 22PF-5UD | Flow sensor 3/4 | Δp1.75kPa | FS13GPM

Product Description

The Belimo 22PF-5UD is a flow sensor designed for measuring fluid flow in heating and cooling systems. With a measurement range of Δp1.75kPa and a flow rate capability of FS13GPM, this ultrasonic sensor provides accurate readings. It features automatic temperature and glycol compensation, making it reliable across various operating conditions.

• Seamless integration with BACnet, Modbus, and MP-Bus protocols.
• Optional heater controls to prevent condensation.
• Easy parameter settings using NFC technology.

Product Highlights

Ideal for applications requiring precise fluid measurement, the Belimo 22PF-5UD improves system performance in HVAC installations.

Product Information

Standard Information

• Fluid: Chilled or hot water, up to 60% glycol
• Application: Pipe

Technical Specifications

• Degree of Protection: IP54, NEMA 2, UL Enclosure Type 2
• Electrical Connection: cable
• Measured Values: Flow, Temperature
• Output Signal: BACnet, Modbus, MP-Bus, 0...10 V, 0.5...10 V, 2...10 V
• Product Type: Sensor
• Sensor Type: Flow
• Voltage AC/DC: 24 V
