Belden 6302FE Security and Sound Cable 500 feet Replacement 7B-6302FE875

Product Description

Belden 6302FE is a high-quality security and sound cable designed to meet the rigorous standards of safety and efficiency in sound and security system installations.

• Features four 18AWG stranded bare copper conductors for reliable signal integrity.
• Enhanced with a low smoke polyvinyl chloride jacket for fire safety in air-handling spaces (Plenum-CMP).
• Capable of supporting a variety of applications including security systems, intercom systems, and power limited controls.

Product Highlights

This cable is ideal for professional installations requiring a CMP rating for plenum spaces. It offers exceptional performance in environments that necessitate strict adherence to safety and quality standards.

Product Information

Standard Information

• Brand: Belden
• MPN: 6302FE

Technical Specifications

• Conductor Count: 4
• Wire Gauge: 18 AWG
• Jacket Type: Plenum
• Cable Length: 500 feet
• Resistance: 21.3265 Ohm/km at 20 deg C
• Temperature Range: 0 to 75 deg C
• Voltage Rating: 300 VAC
• Amperage Rating: 4 A
