Beckett CB504ULHTSP Large Plenum Rated Condensate Pump 460V

Product Description

The BECKETT CB504ULHTSP large plenum rated condensate pump is designed for plenum locations and handles high-temperature condensate up to 212° F. Its robust design promotes efficient, quiet operation and maintains durability. It is an ideal solution for high lift installations up to 50’ lift and is UL/CUL listed.

• Heavy-duty
• Large plenum rated
• Built-in safety switch
• One-gallon tank

Product Highlights

This condensate pump features a replaceable check valve, a pre-wired terminal block, and is capable of handling high-acidity condensation.

Product Information

Standard Information

• Brand: BECKETT
• Manufacturer Part Number: CB504ULHTSP
• Country of Origin: China

Technical Specifications

• Voltage: 460V, 50/60Hz
• Type: Condensate pump
• Brand: Beckett
• Model: CB504ULHTSP
• MPN: CB504ULHTSP
• Power Consumption: 380 Watts
• Flow Rate: 420 GPH at 1 ft
• Maximum Lift: 50 ft
• Discharge Size: 1/2" Copper Compression
• Tank Capacity: 1 US Gallon
• Safety Switch: Built-in
• Design: Reliable two-float design for efficient and quiet operation
• Application: Suitable for AC units, humidifiers, dehumidifiers, high-efficiency furnaces, boilers, and other equipment
• Plenum Rated: UL tested to UL2043 for plenum applications
• Country of Origin: China
• Pump Voltage: 460 Volts
