Beckett 1502S safety control switch 24 VAC

Product Description

The BECKETT 1502S float activated safety switch provides a reliable way to monitor high water levels. It can be wired to turn off air conditioner or furnace equipment, or to sound an alarm if the water level is too high. Designed for easy installation with a stainless steel attachment clip, it requires no mounting screws or special hardware.

• Monitors high water levels and shuts equipment down before overflow occurs.
• Can be wired to turn off A/C or furnace equipment or sound an alarm.
• Easy to install with no tools; features gripping metal bolts for drain pans as shallow as 1.5 in. deep.

Product Highlights

This safety switch is safe for low voltage 24 VAC, 5-amp applications and activates at 3/4 in. from condensate overflow. It features superior clamp strength with galvanized zinc-plated metal wing nut bolts and a protected float enclosure with test tab.

Product Information

Standard Information

• Brand: BECKETT
• Manufacturer Part Number: 1502S
• Country of Origin: China

Technical Specifications

• Manufacturer: Beckett Corporation
• Brand: Beckett
• Model / MPN: 1502S
• Product Type: ELECTRONIC_SWITCH
• Number of Items: 1.0
• Material: Plastic
• Voltage: 24V
• Application: Condensate (HVAC), Drain Pan (HVAC)
