BASO K15DA-18H Standard Thermocouple 18 Inch 1500 deg F

Product Description

The BASO K15DA-18H Standard Thermocouple is engineered to provide reliable performance and durability for heating controls. Ideal for applications in standing pilot ignition systems, this thermocouple includes an 18 inch probe that withstands temperatures up to 1500 degrees Fahrenheit.

• Heavy-duty brass and copper construction ensures longevity.
• Features a built-in junction block for additional high limit switch integration.
• Nickel-plated for corrosion resistance and improved performance in harsh environments.

Product Highlights

This thermocouple is specially designed for both natural and liquefied petroleum gas types, making it versatile for various installations. Its high performance capacity is certified under ANSI Z21-20-1995 and AGA 20-35C-TC standards.

Product Information

Standard Information

• Probe Length: 18 inches
• Temperature Capability: Up to 1500 degrees Fahrenheit

Technical Specifications

• Construction Material: Brass/Copper
• Output Voltage: 8 mV
• Open Circuit Output: 20 - 28 mV
