Barnes & Jones BJV-2L B&J BJV-2L - 1/2 Vertical Bronze Thermostatic Radiator Trap Replacement MPN

Product Description

The Barnes & Jones thermostatic radiator steam trap, model BJV-2L, has a one-half inch trap connection in a vertical orientation. This model is ideal for low pressure heating systems. It operates by responding to steam presence; when steam is detected, it closes, and when cooler air or condensate emerges, it opens. This allows for efficient drainage of condensate.

• One-half inch trap size.
• Vertical mounting for easy installation.
• Operates at a maximum pressure of twenty-five psi.

Product Highlights

This thermostatic steam trap is designed to manage condensate effectively, helping to maintain system efficiency.

Product Information

Standard Information

• Brand: Barnes & Jones
• MPN: BJV-2L

Technical Specifications

• Steam Trap Type: Thermostatic
• Body Material: Bronze
• Steam Trap Connection Size: 1/2
• Steam Trap Mounting: Vertical
• Max Pressure: 25 psi
• Replaces: Barnes & Jones 122V
• Weight: 1.40 lbs
