Barksdale 426T4-13 Pressure Transducer 3000 Psi Npt

Product Description

The BARKSDALE 426T4-13 is a pressure transducer rated to 3,000 psi maximum, designed for accurate pressure sensing in industrial fluid and gas systems. It delivers a 1 to 11 VDC output signal and achieves 0.25% accuracy, making it suitable for applications where precise pressure monitoring is critical. The transducer connects via a 1/4-18 NPT male thread and uses an M12 Hirschman connector for the electrical termination. It operates across a temperature range of -40 to 185 degrees F with a maximum supply voltage of 30 volts. Licensed instrumentation technicians, mechanical contractors, and industrial service professionals are the typical installers of this device.

This transducer is suited for use in hydraulic systems, compressed air circuits, water treatment equipment, and industrial process lines where continuous pressure monitoring is required. It fits residential and commercial mechanical systems as well as light industrial applications. The M12 Hirschman connector allows for quick field wiring without soldering, which is practical in panel or machine installations. Where the 1/4-18 NPT male port is a standard fit, this transducer drops into existing manifold or pipe taps with minimal modification.

Key Features

• 3,000 psi maximum pressure rating for high-pressure system compatibility
• 0.25% accuracy for precise, reliable pressure measurement
• 1 to 11 VDC output signal for direct interface with controllers and PLCs
• 1/4-18 NPT male connection for standard pipe and manifold fitment
• M12 Hirschman connector simplifies field wiring
• Wide operating temperature range: -40 to 185 degrees F

Compatibility

Designed as an OEM-style replacement or direct-install pressure transducer for industrial and mechanical systems using a 1/4-18 NPT male port and a 1 to 11 VDC signal interface.

Installation Notes

Installation should be performed by a qualified instrumentation technician or licensed mechanical contractor. De-energize the system and relieve all line pressure before removing or installing any pressure transducer. Apply thread sealant appropriate for the process fluid to the NPT threads and avoid over-tightening, which can damage the port or sensor body. Verify supply voltage does not exceed 30 volts before connecting the M12 Hirschman wiring harness.
