Product Description
The BANNER 103010N is a reliable R-14 air brake relay valve designed for air brake systems. This valve has multiple ports allowing for delivery, supply, control, and balance connections, each with different thread sizes. It includes a mounting bracket for easy installation.
- Features multiple ports for connection.
- Equipped with a mounting bracket.
- Suitable for air brake system applications.
Product Highlights
The BANNER 103010N air brake relay valve ensures efficient operation in air brake systems with its robust design.
Product Information
Standard Information
-
Brand: BANNER
-
MPN: 103010N
Technical Specifications
-
Crack Pressure: 4 psi
-
Delivery Port Quantity: 2
-
Number Of Supply Port: 2
-
Exhaust Port Type: Dust Shield
-
Minimum Operating Temperature: -40 Deg.F
-
Maximum Operating Temperature: 200 Deg.F
-
Length: 138 mm
-
Width: 102 mm
-
Height: 113 mm
-
Mounting Dimension: 0.96 X 0.40 in
-
Delivery Port Thread Size: 1/2 NPT in
-
Control Port Thread Size: 1/4-18 NPT in
-
Balance Port Thread Size: 1/8-27 NPT in
-
Supply Port 1 Thread Size: 3/4-14 NPT in
-
Control Port Position: 0 deg
-
Delivery Port 1 Thread Size: 1/2-14 NPT in
-
Delivery Port 2 Thread Size: 1/2-14 NPT in
-
Supply Port 2 Thread Size: 3/4-14 NPT in
-
Service Rear Port: 1/2 PTC
-
Stop Light Switch Port: 1/4 PTC
-
Tractor Protection Control Delivery Port: 3/8 PTC
-
Trailer Emergency Supply Port: 3/8 PTC
-
Trailer Service Supply Port: 1/2 PTC
-
Trailer Control Port: 3/8 PTC
-
Service Front Port: 1/2 PTC
