Baldor VEM31115 1hp 3450rpm 3ph 60hz 56c 3420m Open F1 N

Product Description

The BALDOR VEM31115 motor is a 1 HP, 3450 RPM, 3-phase, 60 Hz unit with a 56C frame. This open drip-proof (ODP) motor is designed for general purpose applications, featuring a C-face footless mounting. It operates at 230/460V and offers premium efficiency, making it suitable for various industrial uses such as pumps, fans, and conveyors. The motor is built for continuous duty and reversible shaft rotation.

• 1 HP, 3450 RPM, 3-phase motor with 60 Hz frequency
• Features a 56C frame and an Open Drip Proof (ODP) enclosure
• Designed for C-Face footless mounting and offers premium efficiency

Product Highlights

This general purpose motor is suitable for continuous duty, offering reversible shaft rotation and adherence to NEMA motor standards.

Product Information

Standard Information

• Brand: BALDOR
• Manufacturer Part Number: VEM31115

Technical Specifications

• Output Horsepower: 1 HP
• Speed: 3450 RPM
• Phase: 3
• Frequency: 60 Hz
• Frame: 56C
• Voltage: 230/460V
• Enclosure Type: ODP
• Mounting Type: C-Face Footless
• Efficiency Class: Premium Efficiency
• Manufacturer: BALDOR
• Product Type: Mechanical Components
• Catalog Number: VEM31115
• Frame Material: Steel
• Synchronous Speed: 3600 RPM
• Hazardous Area Class and Group: None
• Hazardous Area Division: Not Applicable
• Agency Approvals: CURUSEEV
• Ambient Temperature: 40 °C
• Auxiliary Box: No Auxiliary Box
• Auxiliary Box Lead Termination: None
• Bearing Grease Type: Polyrex EM (-20F to +300F)
• Blower: None
• Current at Voltage: 1.6 A @ 460V, 2.9 A @ 208V, 3.2 A @ 230V
• Design Code: B
• Drip Cover: Yes
• Duty Rating: Continuous
• Efficiency at 100% Load: 77%
• Electrically Isolated Bearing: No
• Feedback Device: No Feedback
• Front Shaft Indicator: None
• Heater Indicator: No Heater
• Insulation Class: F
• Inverter Code: Not Inverter
• KVA Code: L
• Lifting Lugs: No
• Locked Bearing: Yes
• Motor Lead Exit: KO Box
• Motor Lead Termination: Flying Leads
• Motor Lead Quantity/Wire Size: 9 @ 18 AWG
• Motor Type: 3420M
• Mounting Arrangement: F1
• Number of Poles: 2
• Power Factor: 82%
• Pulley End Bearing Type: Ball
• Pulley Shaft Indicator: Standard
• Rodent Screen: None
• RoHS Status: Compliant
• Service Factor: 1.25
• Shaft Extension Location: Pulley End
• Shaft Grounding: No
• Shaft Rotation: Reversible
• Shaft Slinger: No
• Speed Code: Single Speed
• Motor Standards: NEMA
• Starting Method: Direct On Line
• Thermal Device - Bearing: None
• Thermal Device - Winding: None
• Vibration Sensor: No
• Nameplate Specification: 34F012-3226G1
• Nameplate CC: DE 6203 ODE 6203
• Nameplate Usable At: 50Hz 1HP 190/380V 3.4/1.7A SF1.0
• Output Power: 0.75 kW
• Enclosure IEC Rating: IP22
• Motor Category: AC Motors
• Family Name: Three Phase Open Family
• Series: GO3 Series
• UPC Code: 781568764626
