Baldor Motor EM4115T-G Industrial Electric Motor 50 HP (326T Frame)

Product Description

Baldor Motor EM4115T-G is a 50 HP, three-phase industrial electric motor rated for continuous duty at 60 Hz with a running speed of 1775 rpm (synchronous 1800 rpm). It is built in a 326T iron frame with a TEFC enclosure, rigid base (F1) mounting, and NEMA Premium efficiency (94.5% at full load). The inverter-ready motor includes a 2.125 in shaft, ball bearing on the pulley end, H insulation class, and nine 6 AWG flying leads.

• 50 HP, three-phase, 60 Hz, 1775 rpm; 4 poles; continuous duty
• 326T iron frame, TEFC enclosure, rigid base (F1) mounting; overall length 30.28 in
• Inverter-ready design, NEMA Premium 94.5% efficiency, 9 flying leads (9 @ 6 AWG); 58 A @ 460 V full load

Product Highlights

50 HP TEFC industrial motor, 326T frame, inverter-ready, 9 x 6 AWG flying leads, 2.125 in shaft

Product Information

Standard Information

• Brand: BALDOR MOTOR
• Manufacturer Part Number: EM4115T-G

Technical Specifications

• Brand: Baldor Motor
• Manufacturer Part Number: EM4115T-G
• Product Type: Industrial electric motor
• Power: 50 HP
• Phase: Three
• Frequency: 60 Hz
• Speed: 1775 RPM
• Synchronous Speed: 1800 RPM
• Number of Poles: 4
• Frame: 326T
• Enclosure Rating: TEFC
• Frame Material: Iron
• Mounting Type: Rigid base (F1)
• Voltage: 460 V; 230 V
• Full Load Current: 58 A @ 460 V; 116 A @ 230 V
• Efficiency: 94.5% at 100% load
• Service Factor: 1.15
• Insulation Class: H
• Power Factor: 0.85 (85%)
• Motor Lead Termination: Flying leads
• Motor Lead Quantity/Wire Size: 9 @ 6 AWG
• Shaft Diameter: 2.125 in
• Shaft Extension Location: Pulley end
• Pulley End Bearing Type: Ball
• Duty Rating: Continuous
• Ambient Temperature Rating: 40 �C
• Inverter Ready: Yes
• Overall Length: 30.28 in
• Bearing Grease Type: Polyrex EM (-20�F to +300�F)
• Product Family: General Purpose
• Motor Standards: NEMA
• Starting Method: Direct on line (DOL)
• Auxiliary Box: No
• Heater Indicator: No
• Drip Cover: No
• Shaft Grounding: Yes
• Shaft Slinger: Yes
