Baldor Motor ECS101T8H2DF4 General Purpose Motor 2 HP

Product Description

The Baldor Motor ECS101T8H2DF4 is a three-phase motor delivering two horsepower. It operates efficiently at a speed of 1800 RPM and a frequency of sixty Hertz. This motor features a 145T frame and a totally enclosed fan-cooled enclosure, ensuring durability in various applications.

• Direct-on-line starting capability.
• Reversible shaft rotation for versatile installation.
• Compliant with RoHS and NEMA standards.

Product Highlights

Designed for continuous duty applications, the Baldor Motor ECS101T8H2DF4 is suitable for situations requiring reliable performance.

Product Information

Standard Information

• Manufacturer: Baldor-Reliance
• MPN: ECS101T8H2DF4

Technical Specifications

• Horsepower: 2.0 HP
• Speed: 1800 RPM
• Phase: 3
• Frequency: 60.00 Hz
• Frame Size: 145T
• Enclosure: TEFC
• Voltage: 230.0 V
• Current: 4.800 A
• Duty Rating: CONT
• Shaft Diameter: 0.875 IN
• Shaft Rotation: Reversible
• Weight: 42 lbs
