Baldor EJMM3550T 1.5hp 3500rpm 3ph 60hz 3520m

Product Description

The Baldor EJMM3550T motor is a 1.5 horsepower, 3-phase, 60 Hz electric motor designed for general purpose applications. Operating at 3500 RPM, this TEFC enclosed motor features a steel frame and a rigid base for stable mounting. It is inverter-ready and RoHS compliant, suitable for various industrial and commercial settings requiring reliable power. The motor supports 230V and 460V at 60 Hz, with a service factor of 1.15, ensuring robust performance.

• NEMA Premium efficiency for energy savings and reduced operating costs.
• Inverter Ready design allows for variable speed control in diverse applications.
• Reversible shaft rotation provides versatile integration options for machinery.

Product Highlights

This Baldor EJMM3550T motor offers 1.5HP, 3500 RPM, and 3-phase operation, featuring a TEFC enclosure and NEMA Premium efficiency for diverse industrial uses.

Product Information

Standard Information

• Brand: BALDOR
• Manufacturer Part Number: EJMM3550T

Technical Specifications

• Catalog Number: EJMM3550T
• Enclosure Type: TEFC
• Frame Size: 143JM
• Frame Material: Steel
• Frequency: 60.00 Hz
• Phase Type: Three Phase
• Output Power: 1.500 HP @ 60 HZ
• Phase: 3
• Synchronous Speed: 3600 RPM @ 60 HZ
• Voltage: 230.0 V @ 60 HZ, 460.0 V @ 60 HZ
• Hazardous Area Class: None
• Hazardous Area Division: Not Applicable
• Agency Approvals: CURUSEEV, NEMA PREMIUM
• Ambient Temperature: 40 °C
• Auxiliary Box: No Auxiliary Box
• Auxiliary Box Lead Termination: None
• Mounting Base: Rigid
• Bearing Grease Type: Polyrex EM (-20F +300F)
• Blower: None
• Current at 208V: 4.000 A
• Current at 230V: 3.800 A
• Current at 460V: 1.900 A
• Design Code: B
• Drip Cover: No Drip Cover
• Duty Rating: CONT
• Efficiency at 100% Load: 84.0 %
• Electrically Isolated Bearing: Not Electrically Isolated
• Feedback Device: No Feedback
• High Voltage Full Load Amps: 1.9 A
• Front Face Code: Standard
• Front Shaft Indicator: None
• Heater: No Heater
• Insulation Class: F
• Inverter Compatibility: Inverter Ready
• IP Rating: NONE
• KVA Code: L
• Lifting Lugs: No Lifting Lugs
• Locked Bearing: Locked Bearing
• Motor Lead Exit: Ko Box
• Motor Lead Termination: Flying Leads
• Motor Lead Quantity/Wire Size: 9 @ 18 AWG
• Motor Model: 3520M
• Mounting Arrangement: F1
• Number of Poles: 2
• Power Factor: 85
• Product Family: General Purpose
• Pulley End Bearing Type: Ball
• Pulley Face Code: C-Face
• Pulley Shaft Indicator: Tapped & Key
• Rodent Screen: None
• RoHS Status: ROHS COMPLIANT
• Service Factor: 1.15
• Shaft Extension Location: Pulley End
• Shaft Grounding: No Shaft Grounding
• Shaft Rotation: Reversible
• Shaft Slinger: Shaft Slinger
• Speed: 3500 rpm
• Speed Type: Single Speed
• Motor Standards: NEMA
• Starting Method: Direct on line
• Bearing Thermal Device: None
• Winding Thermal Device: None
• Vibration Sensor: No Vibration Sensor
• Winding Thermal 1: None
• Winding Thermal 2: None
• Nameplate CC: 010A
• Nameplate DE: 6206
• Nameplate ODE: 6203
• Nameplate VPWM: Inverter Ready
• Nameplate SFA: 4.4/2.2
• Nameplate CT6-60H: (10:1)VT3-60H(20:1)
• Nameplate 50Hz Rating: 1.5HP 190/380V 4.6/2.3A SF1.0
• Nameplate NP: 3441LUA
• Line-Line Resistance at 25C (460V): 12.2 Ohms A Ph / 0 Ohms B Ph
• Line-Line Resistance at 25C (230V): 3.04 Ohms A Ph / 0 Ohms B Ph
• Temperature Rise at Rated Load: 43° C
• Temperature Rise at SF Load: 50° C
• Start Configuration: DOL
• Break-Down Torque: 9.49 LB-FT
• Pull-Up Torque: 3.61 LB-FT
• Locked-Rotor Torque: 7.35 LB-FT
• Starting Current (460V): 17.9 A
• Starting Current (230V): 35.8 A
