Balax 30063-000 Spiral Point Tap 10-24 Unc Plug Chamfer Hss

Product Description

The BALAX 30063-000 is a spiral point tap designed for through-hole threading in a wide range of metals and alloys. Built from M42 powdered metal high-speed steel (PM-HSS) in a bright, uncoated finish, this tap delivers consistent thread cutting performance across production and repair applications. It is ground to a 3B class of fit with an H3 thread limit, producing 10-24 UNC threads. The plug chamfer (5-6 threads of lead) makes it well suited for through-hole applications where the tap can advance freely. Licensed HVAC, plumbing, and mechanical contractors, machinists, and industrial maintenance technicians are the typical users of this tool.

This tap is used in through-hole threading operations on low-carbon steel, 300 series stainless steel, wrought aluminum alloy, die cast aluminum, die cast zinc, magnesium, copper, brass, and bronze castings. It is part of the BX100 series and is appropriate for both manual and machine tapping setups where a right-hand, spiral point tool is required. Its 3-flute geometry pushes chips ahead of the tap, keeping the flutes clear during the cut and making it a practical choice for production environments.

Key Features

• 10-24 UNC thread form, right-hand direction, 3B class of fit with H3 thread limit
• Spiral point (gun tap) geometry pushes chips forward, ideal for through-hole threading
• M42 powdered metal high-speed steel construction for improved wear resistance over standard HSS
• Plug chamfer provides 5-6 threads of lead for reliable thread starting
• Bright, uncoated finish compatible with a broad range of cutting fluids and materials
• 3 flutes with no coolant-through requirement, suitable for standard machine and hand tapping setups

Compatibility

Designed for through-hole threading in low-carbon steel, 300 stainless steel, wrought aluminum alloy, die cast aluminum, die cast zinc, magnesium, copper, brass, and bronze castings. Part of the BALAX BX100 series.

Installation Notes

This tap is installed by machinists or maintenance technicians using a tapping machine, drill press, or hand tap wrench. Always ensure the workpiece is secured and the tap is properly aligned with the pre-drilled hole before starting. Apply an appropriate cutting fluid for the material being tapped to extend tool life and improve thread quality. Never reverse a spiral point tap under load without fully disengaging - doing so can chip or break the tap.
