B-Line DPC635 ETN-LIPE PROT CAP,35KV,600A,

Product Description

The B-Line DPC635 ETN-LIPE protective cap is designed for deadbreak applications. This product is part of the Cooper Power Series and provides excellent reliability with a voltage rating of thirty-five kilovolts. It features a drain wire with permanent studs, ensuring effective grounding and protection against power surges.

• Rated for thirty-five kilovolts.
• Includes a drain wire with permanent studs.
• Ideal for utility applications with a capacity of six hundred amps.

Product Highlights

This product is designed for utility use and complements underground systems requiring deadbreak connections.

Product Information

Standard Information

• Brand: B-Line
• Sub Brand: Cooper Power Series

Technical Specifications

• Type: Deadbreak Protective Cap
• Applications: Utility
• Voltage Rating: 35 kV
• Phase to Ground Voltage: 21.1 kV
• AC Test Voltage: 50.0 kV
• DC Test Voltage: 103.0 kV
• BIL: 150.0 kV
• Min Corona Voltage: 26.0 kV
• Weight: 2 lb
• Height: 6.9 inches
• Length: 3.25 inches
• UPC: 784216281650
