B-Line B202-1ZN CLAMP CONDUIT/PIPE 1000LB 7-5/8IN

Product Description

The B-Line B202-1ZN is a conduit and pipe clamp designed for secure application in various industrial settings. This two-piece clamp is made from low carbon steel and zinc plated for enhanced durability. It is rated for a design load safety factor of five, ensuring safe and reliable use in numerous applications.

• 2-piece construction
• Design load safety factor of 5
• Supports 1000 lb vertical load, 250 lb transverse load, and 200 lb longitude load capacity

Product Highlights

The B-Line B202-1ZN is suitable for use with a five-eighths inch bolt and features a nominal size of eleven-sixteenths inch.

Product Information

Standard Information

• Manufacturer: EATON
• Brand: B-Line

Technical Specifications

• Material: Low Carbon Steel
• Finish: Zinc Plated
• Nominal Size: 11/16 inch
• Outside Diameter: 7-5/8 inches
• Inside Diameter: 11/16 inch
• Suitable For Use With: 5/8 inch Bolt
• Load Capacity: 1000 lb vertical, 250 lb transverse, 200 lb longitudinal
• Standards/Approvals: ASTM B633 SC3 Type III/A653/A1011HSLA Grade 50
