Azure Home Products 10874 Ecm Condenser Fan Motor 1/3 Hp

Product Description

The AZURE HOME PRODUCTS 10874 is an ECM condenser fan motor designed for air-cooled condensing units in residential and light commercial HVAC systems. It delivers variable output from 1/8 to 1/3 HP, operating on 208 to 230 volts AC single-phase at 50/60 Hz, with dual speed ratings of 825 and 1075 RPM. The electronically commutated motor design eliminates the need for a run capacitor, reducing component count on the installation. Class B insulation and ball bearing construction support reliable performance in outdoor condenser applications. A stud mount base and water slinger on the shaft complete the assembly.

This motor is suited for condenser fan replacement in residential split systems and packaged units. Its self-adjusting reversible rotation allows the technician to set airflow direction in the field without rewiring. The multi-horsepower range and wide voltage tolerance make it a practical stock item for HVAC service contractors handling a range of condensing unit brands and tonnages. The NEMA 48 frame fits a broad set of standard motor housings commonly found in outdoor condensing sections.

Key Features

• ECM design — no run capacitor required
• Multi-horsepower output: 1/8 to 1/3 HP
• Self-adjusting reversible rotation, field-configurable
• Dual speed: 825 and 1075 RPM
• Ball bearing construction for outdoor condenser duty
• Water slinger on shaft to protect bearings from moisture
• UL approved

Compatibility

Designed as an OEM-style ECM replacement condenser fan motor for residential and light commercial air conditioning condensing units using a NEMA 48 frame stud-mount motor in the 1/8 to 1/3 HP range.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the condensing unit before removing the existing motor. Because this is a no-capacitor ECM unit, verify that any existing run capacitor wiring is properly capped or removed during installation. Confirm shaft rotation direction matches the original equipment requirement before restoring power.

Technical Specifications

• Application: Condenser Fan
• Power Rating: 1/8 to 1/3 HP
• Voltage Rating: 208 to 230 volts AC, 1-Phase
• Frequency Rating: 50/60 Hz
• Speed Rating: 825/1075 RPM
• Number of Speeds: 1
• Motor Type: ECM
• Insulation Class: B
• Bearing Type: Ball Bearing
• Enclosure Type: CAO
• Mounting: Stud
• NEMA Frame Size: 48
• Reversible: Yes
• Approval: UL

Standard Information

• Brand: AZURE HOME PRODUCTS
• Manufacturer Part Number: 10874
