Atlas re5706611 Sediment Cartridge 25 Micron 4.5x10 in

Product Description

The ATLAS re5706611 is a melt-blown polypropylene sediment filter cartridge designed for whole-house and commercial water filtration applications. Built from a single body of polypropylene microfibers with no internal core or support plates, this double open-end (DOE) cartridge delivers a nominal filtration rating of 25 microns. It measures 4.5 inches in outer diameter and 10 inches in height, fitting standard Big Blue-style filter housings. The manufacturing process eliminates direct operator contact with the finished cartridge, supporting hygienic safety standards suitable for potable water systems. Licensed plumbers and water treatment technicians are the primary installers.

This cartridge is suited for residential and light commercial water treatment systems where sediment reduction from incoming supply lines is required. The 25-micron rating targets coarse sediment — sand, rust, and scale particles — making it an appropriate first-stage filter in multi-stage treatment trains. It is rated for flow rates up to 2,500 liters per hour and operates across a temperature range of 39.2 to 176 degrees F, supporting both cold and hot water supply applications.

Key Features

• 25-micron nominal filtration rating targets sand, rust, and coarse sediment
• Melt-blown polypropylene construction — no internal core or plates, single-body design
• Double open-end (DOE) configuration for broad housing compatibility
• Rated for flow rates up to 2,500 liters per hour
• Operating temperature range of 39.2 to 176 degrees F
• Manufactured without direct operator contact for hygienic safety in potable water service

Compatibility

Designed as an OEM-style replacement sediment cartridge for Big Blue-style filter housings accepting 4.5-inch outer diameter by 10-inch DOE cartridges in residential and light commercial water filtration systems.

Installation Notes

Installation should be performed by a licensed plumber or qualified water treatment technician in accordance with local plumbing codes and IPC guidelines. Shut off the water supply and relieve system pressure before opening the filter housing. Inspect the housing O-ring for wear and replace if needed before seating the new cartridge. Do not exceed the rated flow rate or temperature limits for this cartridge.
