ATCO RUBBER PRODUCTS 17802516 Flexible Air Duct R8 16 in x 25 ft

Product Description

The ATCO RUBBER PRODUCTS 17802516 is a flexible air duct designed for low-pressure air moving systems. This product is made using fiberglass duct material combined with a polyester jacket, providing excellent insulation and airflow efficiency. The duct has a round design with a sixteen-inch inside diameter and a length of twenty-five feet. It features a double-ply vapor barrier reinforced in three directions for added durability.

• Maximum air speed of five thousand feet per minute
• Insulation value of R 8.0
• UL listed for safety compliance

Product Highlights

This insulated flexible duct is suitable for various applications that involve air movement, ensuring reliable performance under low pressure.

Product Information

Standard Information

• Brand: Atco Rubber Products
• Model Number: 17802516

Technical Specifications

• Diameter: 16 inches
• Length: 25 feet
• Insulation Value: R 8
• Maximum Airflow: 5000 fpm
• Material: Fiberglass, Polyester
• Vapor Transmission: 0.6%
• Max Pressure: 6 in WC
• Minimum Temperature Rating: -20°F
• Maximum Temperature Rating: 140°F
• Color: Gray
