ATCO PRODUCTS 17802510 Insulated Flexible Duct 10 Inch Diameter

Product Description

The ATCO PRODUCTS 17802510 is an insulated flexible duct ideal for indoor use in low-pressure air moving systems. It is made from fiberglass and polyester, featuring a double-ply vapor barrier along with tri-directional reinforcements for added strength. This duct maintains a smooth interior surface and is designed for nominal duct diameters of ten inches.

• Maximum air speed of five thousand feet per minute.
• Maximum pressure capability of six inches of water column.
• Meets NFPA 90A & B standards for safety.

Product Highlights

This duct is optimized for airflow and insulation, making it suitable for various HVAC applications.

Product Information

Standard Information

• Item: Insulated Flexible Duct
• Environment Type: Indoor

Technical Specifications

• Inside Diameter: 10 inches
• Maximum Temperature Rating: 140°F
• Wall Thickness: 2.5 inches
• Length: 25 feet
• Material: Fiberglass, Polyester
• Max Pressure: 6 inches of water column
• Insulation Value: R 8
• Flame Spread/Smoke Developed: Less than 25/Less than 50
