ATCO PRODUCTS 17802505 5 in x 25 ft Grey R8 Flexible Air Duct

Product Description

The ATCO PRODUCTS 17802505 is a flexible air duct suitable for HVAC applications. It features a robust grey polyester outer jacket reinforced with fiberglass scrim. The air duct has an inner core designed to be airtight, made from double-laminated polyester that includes a steel wire helix for durability. A fiberglass insulation blanket surrounds the inner core, making it efficient for low-to-medium operating pressures. The duct is UL 181 Class 1 listed for safety.

• Airtight inner core enhances energy efficiency.
• The encapsulated wire helix prevents unraveling during use.
• Reinforced polyester jacket offers protection against tearing and punctures.

Product Highlights

This air duct is designed for reliable performance in HVAC systems, ensuring optimum air flow and energy efficiency.

Product Information

Standard Information

• Brand: ATCO PRODUCTS
• MPN: 17802505

Technical Specifications

• Diameter: 5 inches
• Length: 25 feet
• Material: Fiberglass, Plastic, Steel
• Material Type: Polyester
• Color/Finish: Grey
• Jacket Material: Polyester
• Core Material: Fiberglass insulation
• R Value: R8
• UL Listed: UL 181 Class 1
• Vent Duct Shape: Round
• Air Velocity: 5000 fpm
• Burning Character: Maximum Flame Spread 25, Maximum Smoke Developed 50
• Rated Negative Pressure: 3/4 in WG
• Rated Positive Pressure: 10 in WG
• Temperature Rating: -20 to 180 degrees F
• Vapor Transmission: 0.6 perms
• ASTM: ASTM C518
