ATCO PRODUCTS 17602505 076RF 5 x 25' R6 Boxed Flexible Duct

Product Description

The ATCO PRODUCTS 17602505 is a flexible duct designed for HVAC systems. This product features a UL 181, Class 1 certification. It has a tri-directional fiberglass reinforced outer jacket for durability. The duct includes an air-tight inner core that operates effectively at low to medium pressures.

• Air-tight inner core prevents fiberglass erosion into the airflow.
• Smooth interior design minimizes friction loss.
• Durable polyester jacket offers resistance to tearing and puncturing.

Product Highlights

The 17602505 provides superior thermal performance with increased insulation and reduced operational costs.

Product Information

Standard Information

• Brand: ATCO
• Compliance: UL 181 Air Duct

Technical Specifications

• Composition: Polyester
• Core Material: Double ply polyester core
• Flex Length: 25 feet
• Flex Type: Insulated
• Inside Diameter: 5 inches
• Jacket Color: Gray
• Jacket Material: Polyester
• Maximum Air Flow: 5000 feet per minute
• Fire Rating: Flame Spread: 25 max, Smoke Developed: 50 max
• Maximum Pressure: 6 inches W.G. Positive, 4-12 diameter; 4 inches W.G. Positive, 14-20 diameter; 3/4 inches W.G. for all diameters
• R-Value: 6.0
