ATCO PRODUCTS 17002512 Insulated Flexible Duct - 12 inch Diameter

Product Description

The ATCO PRODUCTS 17002512 is an insulated flexible duct made for indoor use. The duct has a smooth, air-tight inner core with an encapsulated wire helix. It features a thick layer of fiberglass insulation and a reinforced gray polyester jacket. This duct is ideal for a nominal diameter of twelve inches and a length of twenty-five feet.

• Features an air-tight inner core and encapsulated wire helix.
• Constructed with fiberglass insulation and a durable polyester jacket.
• Suitable for indoor environments.

Product Highlights

The ATCO PRODUCTS insulated flexible duct is designed for efficient air flow in heating, ventilation, and air conditioning (HVAC) systems. The duct offers a flexible design for easy installation in tight spaces.

Product Information

Standard Information

• Brand: ATCO
• MPN: 17002512

Technical Specifications

• Product Type: Insulated Flexible Duct
• Material: Fiberglass, Polyester
• Inside Diameter: 12 inches
• Overall Length: 25 feet
• Wall Thickness: 1 1/4 inches
• Maximum Air Speed: 5000 FPM
• Maximum Pressure Rating: 6 inches wc
• Maximum Temperature Rating: 180°F
• Minimum Temperature Rating: -20°F
• Insulation Value: R4.2
• Jacket Material: Polyester
• Interior Surface Texture: Smooth
• Vapor Transmission: 0.6%
• Fire Rating: Flame Spread: 25 Max, Smoke Developed: 50 Max
• Standards: CALIFORNIA STATE FIRE MARSHAL, CITY OF CHICAGO, CITY OF SAN FRANCISCO, CUL LISTED, DADE COUNTY, FLORIDA, HUD, IMC, IRC, NEW YORK CITY, NFPA 90A & B, UL LISTED, UMC
