ATCO PRODUCTS 17002507 7 in x 25 ft R4.2 Insulated Flexible Air Duct

Product Description

The ATCO PRODUCTS 17002507 is a flexible air duct designed for HVAC systems. It includes an air-tight inner core and a tri-directional fiberglass scrim reinforced grey polyester outer jacket. The duct is constructed with a steel wire helix encapsulated within a double lamination of polyester. Insulated with fiberglass, it functions effectively for low-to-medium operating pressures.

• Features an air-tight inner core
• Includes an encapsulated wire helix
• Reinforced grey polyester jacket

Product Highlights

This flexible air duct is ideal for various HVAC applications, providing strong insulation and durability for long-term use.

Product Information

Standard Information

• Brand: ATCO
• Manufacturer Part Number: 17002507

Technical Specifications

• Diameter: 7 inches
• Length: 25 feet
• R-Value: R4.2
• Material: Fiberglass, Plastic, Steel, Polyester
• Jacket Color: Gray
• Jacket Material: Polyester
• Core Material: Double ply polyester core
• Maximum Airflow: 5000 FPM
• Maximum Temperature: 250°F (121.11°C)
• Operating Temperature: -20°F to 140°F (-28.8°C to 60°C)
• Fire Rating: Flame Spread: 25 max, Smoke Developed: 50 max
• Compliance: UL 181 Air Duct
• Approvals: UL Listed
• Insulation: R-4.2
• Insulated: Yes
• Vent Duct Shape: Round
• Application: HVAC
• Pressure Rating: 6 in WG
• Minimum Temperature Rating: -20°F
• Maximum Temperature Rating: +140°F
• Specifications Met: ADC Approved, GreenGuard Certified, IMC Certified, IRC Listed, NFPA 90A and 90B, UL 181, UMC10-1
