ATCO PRODUCTS 13602514 036RF 14 x 25' R6 Boxed Flexible Duct

Product Description

The ATCO PRODUCTS 13602514 is a fourteen by twenty-five foot insulated flexible air duct suitable for various HVAC systems. This duct features a reinforced, metallized polyester jacket that protects against tearing and punctures. Inside, it has a double-laminated polyester core that includes a steel wire helix to maintain structure and prevent unraveling when cut. The air-tight core ensures no fiberglass particles enter the airflow, promoting clean air quality.

• Meets UL 181 Class 1 standards for safety.
• Ideal for low-to-medium operating pressures.
• Has R6 insulation for effective thermal performance.

Product Highlights

This duct is engineered for reliable thermal insulation and airflow management. Its design is ideal for both residential and commercial HVAC applications.

Product Information

Standard Information

• Brand: ATCO
• MPN: 13602514

Technical Specifications

• Inside Diameter: 14 inches
• Flex Length: 25 feet
• R-Value: R6
• Flex Type: Insulated
• Jacket Color: Silver
• Jacket Material: Fiberglass scrim reinforced, metallized polyester
• Core Material: Double ply polyester
• Maximum Air Flow: 5000 FPM
• Maximum Pressure: 6 W.G. Positive
• Operating Temperature: -20°F to 140°F
• Vapor Transmission: 0.05 Perms
• Package Type: Box
• Compliance: UL 181, NFPA 90A & 90B, IMC, IRC, UMC 10-1
• Fire Rating: Flame Spread: 25 max, Smoke Developed: 50 max
• Insulated: Yes
