ATCO PRODUCTS 13102514 Insulated Flexible Duct 14 Inch Diameter 25 Foot Length

Product Description

The ATCO PRODUCTS 13102514 is an insulated flexible duct designed for low-to-medium pressure HVAC systems. It features an air-tight inner core made of double-ply polyester, reinforced with a steel wire helix. The duct is wrapped in fiberglass insulation and protected by a metallized polyester jacket. It meets UL 181 Class 1 Air Duct and complies with NFPA 90A & 90B, IMC, IRC, and UMC standards.

• Air-tight inner core prevents fiberglass erosion into the air stream.
• Reinforced metallized polyester jacket resists tears and punctures.
• Suitable for indoor use in low-pressure air moving systems.

Product Highlights

This product is ideal for use in residential and commercial HVAC applications, offering efficient airflow with durability and compliance to safety standards.

Product Information

Standard Information

• Brand: ATCO
• MPN: 13102514

Technical Specifications

• Material: Fiberglass, Metallized Polyester, Polyester
• Inside Diameter: 14 inches
• Length: 25 feet
• Flexibility: Flexible
• Insulation Material: Fiberglass
• Maximum Air Flow: 5000 FPM
• Maximum Pressure: 6 inches wc
• Maximum Temperature: 140 degrees F
• Operating Temperature: -20 degrees F to 140 degrees F (-28.8 degrees C to 60 degrees C)
• Fire Rating: Flame Spread: 25 max, Smoke Developed: 50 max
• Vapor Transmission: 0.05 Perms
• R-Value: R8
• Jacket Color: Silver
• Compliance: UL 181, NFPA 90A & 90B, IMC, IRC, UMC 10-1 (ICC ES REPORT NO. ESR-1268), HUD, Cities of Chicago, New York, San Francisco, County of Dade (Florida)
• Jacket Material: Fiberglass Scrim Reinforced Metalized Polyester
• Core Material: Double ply polyester core
• Wall Thickness: 2.5 inches
