ATCO PRODUCTS 13002510 10 x 25' R4.2 Insulated Flexible Duct

Product Description

The ATCO PRODUCTS 13002510 is a flexible air duct with a diameter of ten inches and a length of twenty-five feet. It has a double-ply polyester core supported by a steel wire helix and is insulated with fiberglass. The exterior is covered with a metallized polyester jacket. This duct meets UL 181 Class 1 standards and is suitable for HVAC systems operating at low to medium pressures.

• Air-tight core minimizes fiberglass contamination.
• Encapsulated helix design prevents unraveling when cut.
• Durable jacket withstands tears and punctures.

Product Highlights

This insulated duct offers reliable thermal insulation and protects against air leaks, making it ideal for indoor applications.

Product Information

Standard Information

• Brand: ATCO PRODUCTS
• MPN: 13002510

Technical Specifications

• Flex Type: Insulated
• Inside Diameter: 10 inches
• Length: 25 feet
• Insulation Material: Fiberglass
• Jacket Material: Metallized Polyester
• Jacket Color: Silver
• R-Value: R4.2
• Maximum Air Flow: 5000 FPM
• Maximum Pressure: 6 in. wc
• Maximum Temperature: 180°F (82.22°C)
• Minimum Temperature: -20°F (-28.8°C)
• Vapor Transmission: 0.05 Perms
• Fire Rating: Flame Spread: 25 max, Smoke Developed: 50 max
• Compliance: UL 181, NFPA 90A & 90B, IMC, IRC, UMC
• Core Material: Double ply polyester core
• Operating Temperature: -20°F to 140°F (-28.8°C to 60°C)
• Flexibility: Flexible
• Environment Type: Indoor
• Wall Thickness: 1 1/4 inches
