ATCO PRODUCTS 13002507 030 Series Insulated Flexible Air Duct 7 in x 25 ft

Product Description

The ATCO PRODUCTS 13002507 is a 030 Series insulated flexible air duct. This duct is built for low-to-medium pressure in HVAC systems, ensuring effective air distribution. The duct features an air-tight inner core. The outer jacket is made from metallized polyester, reinforced with fiberglass scrim, providing both durability and insulation.

• Inside diameter of seven inches.
• Length of twenty-five feet.
• Rated for operation up to two hundred fifty degrees Fahrenheit.

Product Highlights

This product is designed for efficient airflow and insulation. It meets UL 181 standards for safety and performance.

Product Information

Standard Information

• Brand: ATCO PRODUCTS
• MPN: 13002507

Technical Specifications

• Series: 030 Series
• Inside Diameter: 7 inches
• Length: 25 feet
• Flow Rate: 5000 fpm
• Insulation: R4.2
• Material: Polyester/Fiberglass/Metalized Polyester
• Compliance: UL 181
• Composition: Metallized Polyester
• Core Material: Double ply polyester core
• Fire Rating: Flame Spread 25 max, Smoke Developed 50 max
• Flex Type: Insulated
• Maximum Air Flow: 5000 FPM
• Maximum Pressure: 6 W.G. Positive
• Maximum Temperature: 250°F
• Operating Temperature: -20°F to 140°F
• Pressure Rating: 6 W.G. pos.
• R-Value: R4.2
• Vapor Transmission: 0.05 Perms
• Approvals: UL Listed
• Country of Origin: USA
