ATCO PRODUCTS 031 R8 14 Air Duct 14 in 25 ft

Product Description

The ATCO PRODUCTS 031 R8 14 is a UL 181, Class 1 air duct. It has a tri-directional fiberglass scrim reinforced, metallized polyester outer jacket. The air-tight inner core is made for low-to-medium operating pressures in HVAC systems. This duct also features increased insulation for thermal performance.

• Air-tight inner core for energy efficiency.
• Encapsulated wire helix allows for quick installation.
• Smooth inner core reduces friction loss.

Product Highlights

Designed for effective air flow and energy efficiency, this product meets standards for HVAC applications.

Product Information

Standard Information

• Series: R8
• Brand: ATCO PRODUCTS

Technical Specifications

• Inside Diameter: 14 inches
• Length: 25 feet
• Air Flow: 5000 fpm
• Vapor Transmission: 0.05 perms
• Pressure: 10 inches WG
• Jacket: Metallized Polyester
• Flame Spread: 25 maximum
• Smoke Developed: 50 maximum
• R-Value: 8
• Maximum Operating Temperature: -20 to 140 degrees F continuous
• Pressure Ratings: 4 thru 12 inches diameter 6 inches WG maximum positive pressure, 14 thru 22 inches diameter 4 inches WG maximum positive pressure
