ATCO 17802408 8X25 R8 FLEX DUCT GREY JACKET

Product Description

The ATCO 17802408 is an eight-inch by twenty-five-foot flexible air duct. This duct is designed with R8 thick blanket fiberglass insulation, which provides excellent thermal performance. The product meets various applicable standards, ensuring compliance and safety in HVAC applications.

• High air velocity of five thousand feet per minute.
• Constructed with durable gray scrim reinforced polyester.
• Suitable for a wide temperature range from negative twenty to one hundred forty degrees Fahrenheit.

Product Highlights

Ideal for HVAC systems, this ducting offers reliable performance and safety features for efficient air distribution.

Product Information

Standard Information

• Brand: ATCO RUBBER PRODUCTS
• Manufacturer: ATCO RUBBER PRODUCTS INC

Technical Specifications

• Air Velocity: 5000 FPM
• Applicable Standard: ASTM C518, NFPA 90A/90B, ADC, IMC, IRC, UMC 10-1, HUD, UL 181
• Maximum Flame Speed: 25
• Maximum Smoke Developed: 50
• Core Material: Double Lamination Tough Polyester with Steel Wire Helix
• Insulation Type: R8 Thick Blanket Fiberglass
• Jacket Material: Gray Scrim Reinforced Polyester
• Length: 25 Foot
• Rated Negative Pressure: 3/4 Inch WG (Maximum)
• Rated Positive Pressure: 10 Inch WG per UL 181 (Rated), 6 Inch WG (Maximum)
• Temperature Rating: -20 to 140 Deg F (Continuous Maximum Pressure), -20 to 180 Deg F
• Type Class: 1, Plain End
• Width: 8 Inch Diameter
