ATCO 17602405 Insulated Flex Duct 5 inches x 25 feet Gray Air Duct 761094265325

Product Description

Experience the efficiency of the ATCO 17602405, a 5 inch by 25 feet insulated flex duct, designed for reliable performance in HVAC systems. This duct features a robust construction with a tri-directional fiberglass scrim reinforced grey polyester outer jacket and a double-laminated inner core that encapsulates a steel wire helix, ensuring an air-tight seal.

• Energy efficient with a thick blanket of fiberglass insulation for superior thermal characteristics.
• Durable with a tough reinforced grey polyester jacket that is tear and puncture resistant.
• Lightweight design simplifies handling and installation, reducing overall labor and handling costs.

Product Highlights

ATCO's flex ducts are known for their air-tight inner core which prevents fiberglass erosion into the airstream, offering a low friction loss for decreased operating costs. The encapsulated wire helix allows for quick, unravel-free installation.

Technical Specifications

• Brand: ATCO
• MPN: 17602405
• UPC: 671094265325
• Size: 5 inches x 25 feet
• Color: Gray
• R-Value: R6
• Material: Polyester core, Grey Polyester vapor barrier
• Fire Rating: UL 181 Class 1 Air Duct
• Maximum Air Flow: 682 CFM
• Maximum Temperature: 250 degrees Fahrenheit
