Atco 13602520 Insulated Flexible Air Duct 20 in ID x 25 ft L R6 Insulation

Product Description

Atco 13602520 is an insulated flexible air duct designed for efficient airflow in HVAC systems. The duct features a twenty inches inside diameter and a length of twenty-five feet. With a flow rate of five thousand feet per minute, it is suitable for both residential and commercial applications.

• R6 insulation for improved thermal performance.
• Constructed from polyester, fiberglass, and metalized polyester.
• Encapsulated wire helix allows for easy handling and installation.

Product Highlights

This duct is ideal for use as a supply or return air duct in low-to-medium pressure heating and air conditioning systems.

Product Information

Standard Information

• Brand: Atco
• Manufacturer: Atco Rubber Products

Technical Specifications

• Type: Insulated
• Finish: Silver
• Length: 25 ft
• Series: 036 Series
• Material: Polyester/Fiberglass/Metalized Polyester
• Flow Rate: 5000 fpm
• Inside Diameter: 20 in
• Pressure Rating: -3/4 to 4 in-WG
• Insulation Value: R6
• Temperature Rating: -20 to 140 deg F
• Vapor Transmission: 0.05 perm
• Suitable For Use With: Complete Air Duct System and/or a Branch Duct Connecting to Mixing Boxes, Diffusers, Light Troffers, Room Inlets or other Terminal Devices
• Country of Origin: US
