Product Description
The ATCO 13102408 is an eight by twenty-five foot metalled jacket flexible air duct suitable for high-velocity systems. This duct is rated for an air velocity of five thousand feet per minute, making it ideal for commercial and residential HVAC applications.
- R8 thick blanket fiberglass insulation for improved energy efficiency.
- Constructed with double lamination tough polyester and steel wire helix for durability.
- Temperature rated from negative twenty to one hundred forty degrees Fahrenheit.
Product Highlights
This product is designed to provide effective insulation and airflow for various ventilation systems.
Product Information
Standard Information
-
Manufacturer: ATCO Rubber Products Inc
-
Minimum Order Quantity: 1
Technical Specifications
-
Air Velocity: 5000 FPM
-
Applicable Standards: ASTM C518, NFPA 90A/90B, ADC, IMC, IRC, UMC 10-1, HUD, UL 181
-
Maximum Flame Speed: 25
-
Maximum Smoke Developed: 50
-
Core Material: Double Lamination Tough Polyester with Steel Wire Helix
-
Insulation Type: R8 Thick Blanket Fiberglass
-
Jacket Material: Silver Scrim Reinforced Metalized Polyester
-
Length: 25 Foot
-
Rated Negative Pressure: 1 Inch WG (Maximum)
-
Rated Positive Pressure: 10 Inch WG Positive per UL 181 (Rated), 6 Inch WG (Maximum)
-
Temperature Rating: -20 to 140 Deg F (Continuous Maximum Pressure), -20 to 180 D
-
Type: Class 1, Plain End
-
Width: 8 Inch Diameter
