Atco 031 5 R8 Class 1 Insulated Flexible Foil Duct 25 feet Length 5 Inch Diameter

Product Description

The ATCO 031 5 is an R8 Class 1 insulated flexible foil duct with a metalized polyester jacket, polyester core, fiberglass insulation, and scrim. This 30 Series duct is 25 feet in length and 5 inches in diameter, designed for HVAC systems. It features an airtight inner core for low to medium operating pressures.

• Features a tri-directional fiberglass scrim reinforced, metalized polyester outer jacket.
• Airtight inner core ensures energy efficiency and prevents fiberglass erosion into the air stream.
• Suitable for use as a complete air duct system or as a branch duct connecting to various terminal devices.

Product Highlights

Durable and efficient flexible foil duct for HVAC systems, providing excellent thermal characteristics and airtight performance.

Product Information

Standard Information

• Brand: ATCO
• Manufacturer Part Number: 031 5

Technical Specifications

• R-Value: R8
• Series: 30 Series
• Temperature Rating: -20 to 140 deg F
• Velocity Rating: 5000 fpm
• Length: 25 ft
• Diameter: 5 in
• Pressure Rating: 6 in-WC Positive, 1 in-WC Negative
• Material: Metalized Polyester/Polyester/Fiberglass/Scrim
