Aspen AED-L-004+FCLL15 Electric Furnace 15 kW

Product Description

The ASPEN AED-L-004+FCLL15 is an electric furnace designed for manufactured homes. It features a 15 kW heat output at 240V and an airflow rating of 1130-1850 CFM. The unit operates on 208-240/1/60 voltage and has a vertical downflow configuration. The cabinet is a one-piece design, field convertible with the correct door and accessories.

• Convertible one-piece cabinet for flexible airflow orientation.
• Rail-mounted blower assembly for easy service.
• Electrical access from both sides of the cabinet.

Product Highlights

This electric furnace is designed for manufactured homes, offering versatile installation and efficient performance.

Product Information

Standard Information

• Brand: ASPEN
• Manufacturer Part Number: AED-L-004+FCLL15

Technical Specifications

• Brand: Aspen Manufacturing
• Application: Wall/Closet Downflow Manufactured Home Air Handler Indoor
• Tonnage: 3 - 5
• Heat kW @ 240V: 15 kW
• CFM Rating: 1130-1850
• Voltage Data (Volts-Phase-Hz): 208-240/1/60
• Minimum Circuit Amps @ 240V: 59.5/25
• Max Breaker or Fuse size: 60/25
• Airflow Stages: 1 Stage
• Motor: 1 hp
• Phase: 1 Phase
• Configuration: Downflow, Front and Top Return, Louvered Door
• Series: AED Series
• Voltage Rating: 240 V
• Motor Type: ECM
• Type: Electric Furnace
• Fan Motor: Constant Torque ECM
