Ashland Water Group WS714 Cast Iron Well Seal 6 Inch

Product Description

The ASHLAND WATER GROUP WS714 is a two-hole solid top cast iron well seal designed to cap a 6-inch well casing and prevent surface drainage and contaminants from entering the water supply. It features dual pipe openings sized at 1-1/4 inches and 1 inch, accommodating a typical drop pipe and a smaller auxiliary line or wire conduit. Cast iron construction provides corrosion resistance and long-term durability in below-grade or at-grade well head installations. Licensed well drillers and plumbing contractors install this seal as part of a properly grouted and capped potable water well system.

The WS714 is suited for residential and light commercial drilled well applications where a 6-inch steel or PVC well casing is present. The solid top design with two preformed openings covers the full casing opening while allowing simultaneous passage of a submersible pump drop pipe and a separate conduit for electrical wiring. This configuration is common in standard single-pump residential well completions. The seal helps meet local well construction code requirements for sanitary protection at the well head.

Key Features

• Solid top cast iron construction resists corrosion and physical damage at the well head
• Two-hole configuration accepts a 1-1/4 inch drop pipe and a 1 inch secondary line simultaneously
• Fits standard 6-inch well casing for residential and light commercial drilled wells
• Blocks surface drainage, insects, and debris from entering the well bore
• Sold as a single unit for straightforward one-for-one replacement or new installation

Compatibility

Designed as an OEM-style replacement or new-installation well seal for standard 6-inch drilled well casings requiring dual pipe penetrations of 1-1/4 inches and 1 inch.

Installation Notes

Installation is performed by a licensed well driller or plumbing contractor in accordance with applicable state and local well construction codes. Shut off and lock out the submersible pump circuit at the breaker before pulling any drop pipe or disturbing the existing well seal. Inspect the casing top for burrs or damage that could prevent a proper seal seating before installing the new well seal. Do not overtighten compression fittings or pipe clamps beyond manufacturer guidance, as cast iron flanges can crack under excessive torque.

Technical Specifications

• Casing Size: 6 inches
• Pipe Opening 1: 1-1/4 inches
• Pipe Opening 2: 1 inch
• Top Style: Solid Two-Hole
• Material: Cast Iron
• Weight: 6.9 pounds
• Package Quantity: 1

Standard Information

• Brand: ASHLAND WATER GROUP
• Manufacturer Part Number: WS714
