Ashland Water Group SUP55 Submersible Utility Pump 1/4 Hp

Product Description

The ASHLAND WATER GROUP SUP55 is a 1/4 HP submersible utility pump designed for residential water removal applications. Powered by a 115-volt capacitor motor, it delivers up to 1980 gallons per hour and operates on a manual basis, giving the installer direct control over run cycles. The thermoplastic housing resists corrosion and keeps the unit lightweight for easy placement and retrieval. A 10-foot power cord provides reach without an extension cord in most standard utility installations. This pump is typically installed by plumbers or general contractors handling water intrusion service calls.

The SUP55 is suited for pumping water from flooded basements, low-lying areas, window wells, cisterns, and sumps. It can drain from flat surfaces down to 3/8 inches of standing water and handles solids up to 1/8 inches in size, making it practical for environments where light debris or sediment may be present. Its compact submersible design allows it to sit directly in the water source without requiring priming or external suction lines.

Key Features

• 1/4 HP, 115-volt capacitor motor with manual operation
• Flow rate up to 1980 GPH for fast water removal
• Drains flat surfaces down to 3/8 inches of residual water
• Handles solids up to 1/8 inches to reduce clogging risk
• Thermoplastic construction for corrosion resistance and light weight
• 10-foot power cord included for direct outlet reach

Compatibility

Designed as an OEM-style replacement or direct-install submersible utility pump for residential sump, cistern, and water removal applications.

Installation Notes

Installation should be performed by a licensed plumber or qualified service technician following applicable local plumbing codes. Always disconnect power at the outlet or circuit breaker before placing or removing the pump from water. Verify the discharge connection is secure and routed to a safe drain location before energizing the unit. Do not run the pump dry, as this can damage the motor and void the warranty.

Technical Specifications

• Horsepower: 1/4 HP
• Voltage: 115 volts
• Motor Type: Capacitor motor
• Flow Rate: 1980 GPH (max)
• Minimum Drain Depth: 3/8 inches
• Maximum Solids Handling: 1/8 inches
• Power Cord Length: 10 feet
• Construction Material: Thermoplastic
• Operation Mode: Manual
• Weight: 6.5 pounds
• Warranty: 1 year

Standard Information

• Brand: ASHLAND WATER GROUP
• Manufacturer Part Number: SUP55
